Intrinsically safe modular PLC was developed to control and for visualization of machines and equipment operated in underground mines in areas endangered by firedamp and / or coal dust.

The individual components of intrinsically safe programmable driver ATUT-IMPS have independent certificates given by notified certification body to confirm the compliance with ATEX directive, which allows hardware configuration, tailored to the needs of the customer. ATUT-IMPS implementation meets the requirements of IEC 61131 on standardization of functional properties, operating and programming PLCs. For PLC programmers the IEC 61131-3 seems to be the most important part as it defines the programming languages. Compliance with the IEC 61131 standard enables customer to build his own software on the device, which has an impact on the life cycle of code, improves and accelerates the design, its implementation, testing and modernization. Built-in operation system enables to use any of defined in IEC 61131-3 languages such as:

• Instruction List (IL);
• Structured Text (ST);
• Funcion Block Diagram (FBD);
• Ladder Diagram (LD);
• Sequential Function Chart (SFC);
• PLC modules can communicate with each other via one of the three interfaces: I2C, RS-485, CAN.

Intrinsically safe modular PLC ATUT-IMPS is designed for use in most hazardous areas of mining plant where it can be used to:

• Control single conveyor belt or conveyor belts combined into bulk material transportation system
• Control devices for refrigeration and air conditioning of mining plant underground with equipment and a network of chilled water flooding supervision included
• Control of main pumping station
• High-pressure pump control
• Control and monitoring of operating parameters of:
  - fire extinguishing system (intrinsically safe flow meters)
  - air, methane and high-pressure emulsion
• Control the process of unloading the excavated material carried by transportation units
• Control of the shaft devices
• Control the process of loading the excavated coal tanks
• System communication control when used as a network node
• Command or control any machinery, equipment or other process which requires the use of intrinsically safe PLC.

Intrinsically safe modular PLC ATUT-IMPS is designed for use in most hazardous areas of mining plant where it can be used to:

• Main module including communication ports type ATX 412
• LCD display module type ATX 457
• 8 supervised inputs module type ATX 401
• 4 relays outputs module type ATX 406
• 4 analog inputs module type ATX 448
• Keyboard module type ATX 446
• Led synoptic module type ATX 447
• Led display module type ATX 445
• Temperature measurement module type ATX 423
• Acoustic signal generator module type ATX 418
• Safety-relay module type ATX 400
• Media converter module type IKM-1
